PIC24EP64GP204-E/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 64KB FLASH 44TQFP
PDF
/
Inventory: 5285
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-TQFP
Number of Pins 44
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Published 2012
Series Automotive, AEC-Q100, PIC? 24EP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Frequency 60MHz
CPU Family PIC
On Chip Program ROM Width 24
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 9x10b/12b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 64KB 22K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 4K x 16
Number of I/O 35
Oscillator Type Internal
Memory Size 64kB
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 44
Base Part Number PIC24EP64GP204
Time@Peak Reflow Temperature-Max (s) 40
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
