PIC24EP512MC204-H/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 16B MCU 512KB Flsh 48KB RAM QEI MCPWM
PDF
/
Inventory: 8979
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~150°C TA
Packaging Tray
Published 2013
Series Automotive, AEC-Q100, PIC? 24EP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Base Part Number PIC24EP512MC204
Operating Supply Voltage 3.6V
Supply Voltage-Max (Vsup) 3.3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 512kB
Oscillator Type Internal
Number of I/O 35
Speed 60 MIPs
RAM Size 24K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Clock Frequency 60MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 512KB 170K x 24
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Bit Size 16
Data Converter A/D 9x10b/12b
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
On Chip Program ROM Width 8
Number of ADC Channels 9
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
RoHS Status ROHS3 Compliant
