PIC24EP512GP202-I/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 16B MCU 512KB Flsh 48KB RAM OpAmp Cmptr
PDF
/
Buying Options
Total Price: USD $4.84
Unit Price: USD $4.839159
≥1 USD $4.839159
≥10 USD $4.565242
≥100 USD $4.306833
≥500 USD $4.063052
≥1000 USD $3.833061
Inventory: 1612
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2013
Series PIC? 24EP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Frequency 70MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC24EP512GP202
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 512kB
Oscillator Type Internal
Number of I/O 21
RAM Size 24K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 512KB 170K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 6x10b/12b
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 174762
On Chip Program ROM Width 24
CPU Family PIC
Dimensions
Length 34.67mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
