PIC24EP32MC204-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 44QFN
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 395
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-VQFN Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2012
Series PIC? 24EP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 70MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC24EP32MC204
Pin Count 44
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 35
RAM Size 2K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 32KB 10.7K x 24
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Bit Size 16
Data Converter A/D 9x10b/12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 10922
On Chip Program ROM Width 24
CPU Family PIC
Dimensions
Height Seated (Max) 1mm
Length 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
