PIC24EP256MC204-E/TL
RoHS
RoHS compliant
RoHS compliantPackage 44-VFTLA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 44VTLA
PDF
/
Inventory: 8891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 6mm
Height Seated (Max) 1mm
Technical
CPU Family PIC
On Chip Program ROM Width 24
ROM (words) 87381
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Data Converter A/D 9x10b/12b
Bit Size 16
Supply Current-Max 55mA
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 256KB 85.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 16K x 16
Speed 60 MIPs
Number of I/O 35
Oscillator Type Internal
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Pin Count 44
Base Part Number PIC24EP256MC204
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Terminal Finish NICKEL PALLADIUM GOLD
ECCN Code 3A001.A.3
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Series Automotive, AEC-Q100, PIC? 24EP
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-VFTLA Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
