PIC24EP128MC204-E/TL
RoHS
RoHS compliant
RoHS compliantPackage 44-VFTLA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 128KB FLASH 44VTLA
PDF
/
Inventory: 5413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-VFTLA Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2013
Series Automotive, AEC-Q100, PIC? 24EP
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
ECCN Code 3A001.A.3
Terminal Finish MATTE TIN
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number PIC24EP128MC204
Pin Count 44
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Oscillator Type Internal
Number of I/O 35
Speed 60 MIPs
RAM Size 8K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Clock Frequency 60MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 128KB 43K x 24
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Supply Current-Max 55mA
Bit Size 16
Data Converter A/D 9x10b/12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
ROM (words) 43690
On Chip Program ROM Width 24
CPU Family PIC
Dimensions
Height Seated (Max) 1mm
Length 6mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
