PIC24EP128MC202-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 128KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.776784
≥1 USD $2.776784
≥200 USD $1.075265
≥500 USD $1.037191
≥1000 USD $1.01881
Inventory: 2826
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10.2mm
Height Seated (Max) 2mm
Technical
CPU Family PIC
On Chip Program ROM Width 24
ROM (words) 43690
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 6x10b/12b
Bit Size 16
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 8K x 16
Number of I/O 21
Oscillator Type Internal
Memory Size 128kB
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 28
Base Part Number PIC24EP128MC202
Time@Peak Reflow Temperature-Max (s) 40
Frequency 70MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A001.A.3
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 24EP
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
