PIC24EP128MC202-H/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit PIC24E PIC Harvard 128KB Flash 3.3V 28-Pin SOIC W Tube
PDF
/
Inventory: 3049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 21
Max Frequency 60MHz
Core Architecture PIC
Number of Timers/Counters 5
Data Bus Width 16b
Watchdog Timer Yes
Data Converter A/D 6x10b/12b
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 3V~3.6V
Memory Type FLASH
RAM Size 8K x 16
Speed 60 MIPs
Number of I/O 21
Oscillator Type Internal
Memory Size 128kB
Min Supply Voltage 2.95V
Max Supply Voltage 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Operating Supply Voltage 3.3V
Base Part Number PIC24EP128MC202
Frequency 70MHz
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q100, PIC? 24EP
Published 2012
Packaging Tube
Operating Temperature -40°C~150°C TA
Physical
Supplier Device Package 28-SOIC
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
