PIC18LF6520T-I/PTG
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 32KB 2048 RAM 52I/O Lead Free Package
PDF
/
Inventory: 9716
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
On Chip Program ROM Width 16
EEPROM Size 1K x 8
ROM (words) 16384
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 40 μs
Watchdog Timer Yes
Data Converter A/D 12x10b
Bit Size 8
Connectivity I2C, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 2K x 8
Number of I/O 52
Oscillator Type Internal
Memory Size 32kB
Interface I2C, SPI, UART, USART
Operating Supply Voltage 5.5V
Pin Count 64
Base Part Number PIC18LF6520
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Additional Feature ALSO OPERATES AT 2V MINIMUM SUPPLY
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18F
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-TQFP
Mounting Type Surface Mount
Alternative Model
