PIC18LF6393T-I/PT
RoHS
/
Package TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 9644
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
RAM (bytes) 768
Number of Programmable I/O 50
CPU Family PIC
On Chip Program ROM Width 16
Core Architecture PIC
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Frequency (Max) 40MHz
Bit Size 8
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type FLASH
RAM Size 768B
Number of I/O 65
Oscillator Type Internal
Power Dissipation-Max 1W
Memory Size 8kB
Min Supply Voltage 2V
Max Supply Voltage 5.5V
Interface EBI/EMI, I2C, SPI, UART, USART, USB
Temperature Grade INDUSTRIAL
Power Supplies 2.5/5V
Pin Count 64
Time@Peak Reflow Temperature-Max (s) 40
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3
Pbfree Code yes
JESD-609 Code e3
Physical
Number of Pins 64
Surface Mount YES
Package / Case TQFP
