PIC18LF46K40-I/MV
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 40UQFN
PDF
/
Buying Options
Total Price: USD $1.83
Unit Price: USD $1.8304
≥1 USD $1.8304
≥10 USD $1.6808
≥100 USD $1.5224
Inventory: 21784
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 40-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Additional Feature IT ALSO OPERATES AT 2.5V MIN AT 32 MHZ AND 1.8V MIN AT 16 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number PIC18LF46K40
JESD-30 Code S-PQCC-N40
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Oscillator Type Internal
Number of I/O 36
Speed 64MHz
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 32K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 35x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 1K x 8
On Chip Program ROM Width 16
Boundary Scan NO
Low Power Mode YES
Screening Level TS 16949
Format FIXED POINT
Integrated Cache NO
RAM (words) 32768
Number of Timers 9
Number of External Interrupts 3
Dimensions
Height Seated (Max) 0.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
