PIC18LF45K80T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 44QFN
PDF
/
Inventory: 8858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-VQFN Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series PIC? XLP? 18K
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Frequency 64MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18LF45K80
Pin Count 44
Interface CAN, I2C, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 35
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity ECANbus, I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 11x12b
Watchdog Timer Yes
Data Bus Width 8b
Number of Timers/Counters 5
EEPROM Size 1K x 8
CPU Family PIC
Number of UART Channels 2
Number of ADC Channels 11
Number of SPI Channels 1
Dimensions
Height 950μm
Length 8mm
Width 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
