PIC18LF45K22-E/P
RoHS
RoHS compliant
RoHS compliantPackage 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 40DIP
PDF
/
Buying Options
Total Price: USD $3.38
Unit Price: USD $3.380718
≥1 USD $3.380718
≥200 USD $1.308961
≥500 USD $1.26301
≥1000 USD $1.239378
Inventory: 6261
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Surface Mount NO
Number of Pins 40
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2010
Series PIC? XLP? 18K
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 40
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO OPERATES 1.8 V MINIMUM SUPPLY AT 16 MHZ
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Supply Voltage 3V
Terminal Pitch 2.54mm
Frequency 48MHz
Base Part Number PIC18LF45K22
Pin Count 40
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 35
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 8
Data Converter A/D 30x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 7
ROM (words) 16384
EEPROM Size 256 x 8
On Chip Program ROM Width 16
CPU Family PIC
Number of Programmable I/O 36
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
