PIC18LF4480T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant GULL WING QUAD Microcontroller 40mus 1W -40C~85C TA 40MHz
PDF
/
Buying Options
Total Price: USD $7.94
Unit Price: USD $7.936481
≥1 USD $7.936481
≥200 USD $3.070873
≥500 USD $2.963215
≥1200 USD $2.910699
Inventory: 996
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
Number of Programmable I/O 25
CPU Family PIC
On Chip Program ROM Width 16
EEPROM Size 256 x 8
ROM (words) 8192
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 40 μs
Watchdog Timer Yes
Data Converter A/D 11x10b
Bit Size 8
Connectivity CANbus, I2C, SPI, UART/USART
Program Memory Size 16KB 8K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 768 x 8
Number of I/O 36
Oscillator Type Internal
Memory Size 16kB
Interface CAN, I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 2V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 44
Base Part Number PIC18LF4480
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 0.8mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18F
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Package / Case 44-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
