PIC18LF4331-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 44QFN
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.0216
≥1 USD $4.0216
Inventory: 109
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8mm
Height Seated (Max) 1mm
Technical
CPU Family PIC
On Chip Program ROM Width 16
EEPROM Size 256 x 8
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 40 μs
Watchdog Timer Yes
Data Converter A/D 9x10b
Bit Size 8
Supply Current-Max 15mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 8KB 4K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LVD, Power Control PWM, QEI, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 768 x 8
Number of I/O 36
Oscillator Type Internal
Memory Size 8kB
Interface I2C, SPI, SSP, UART, USART
Supply Voltage-Min (Vsup) 2V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 44
Base Part Number PIC18LF4331
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18F
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
