PIC18LF27K42-E/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant DUAL CMOS Through Hole Microcontroller -40C~125C TA 64MHz 5.08mm 8K x 8
PDF
/
Buying Options
Total Price: USD $2.92
Unit Price: USD $2.9216
≥1 USD $2.9216
≥10 USD $2.6664
≥100 USD $2.4288
Inventory: 315
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series PIC? XLP? 18K
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO OPERATES WITH 2.3VMIN @ 32MHZ AND 1.8VMIN @ 16MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number PIC18LF27K42
JESD-30 Code R-PDIP-T28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, HLVD, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 128KB 64K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Data Converter A/D 24x12b; D/A 1x5b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
EEPROM Size 1K x 8
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 5.08mm
Length 34.671mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
