PIC18LF27K40T-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 128KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.878609
≥1 USD $1.878609
≥10 USD $1.772277
≥100 USD $1.671952
≥500 USD $1.577314
≥1000 USD $1.488034
Inventory: 1623
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2017
Series PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Additional Feature OPERATES AT 1.8 V MINIMUM SUPPLY AT 16 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC18LF27K40
JESD-30 Code R-PDSO-G28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 128KB 64K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 9.5mA
Bit Size 16
Data Converter A/D 24x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 65536
EEPROM Size 1K x 8
On Chip Program ROM Width 16
Boundary Scan NO
Low Power Mode YES
Screening Level TS 16949
Format FIXED-POINT
Integrated Cache NO
RAM (words) 3728
Number of Timers 7
Number of External Interrupts 3
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 2mm
Length 10.2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
