PIC18LF27K40T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Low-Power High-Performance Microcontroller 128 Kbyte Flash 3728 Byte RAM with XLP Technology 28-Pin QFN T/R
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.8832
≥1 USD $1.8832
≥10 USD $1.716
≥100 USD $1.5488
Inventory: 6288
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Additional Feature OPERATES AT 1.8 V MINIMUM SUPPLY AT 16 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number PIC18LF27K40
JESD-30 Code S-PQCC-N28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 128KB 64K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 24x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 1K x 8
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 1mm
Length 6mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
