PIC18LF25K83-I/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 28SDIP
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.550965
≥1 USD $2.550965
≥200 USD $0.987301
≥500 USD $0.953165
≥1000 USD $0.936098
Inventory: 6235
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 28
Additional Feature OPERATES AT 1.8V MINIMUM SUPPLT AT 16 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC18LF25K83
JESD-30 Code R-PDIP-T28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity CANbus, I2C, LINbus, SPI, UART/USART
Data Converter A/D 24x12b; D/A 1x5b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
EEPROM Size 1K x 8
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 5.08mm
Length 34.671mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
