PIC18LF25K50T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 28QFN
PDF
/
Inventory: 9230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, SPI, UART/USART, USB
Supply Current-Max 10mA
Bit Size 8
Data Converter A/D 14x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 4
EEPROM Size 256 x 8
On Chip Program ROM Width 16
CPU Family PIC
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
Series PIC? XLP? 18K
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.65mm
Frequency 48MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18LF25K50
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 2.7V
Interface I2C, SPI, UART, USART, USB
Memory Size 32kB
Oscillator Type Internal
Number of I/O 25
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Dimensions
Height Seated (Max) 1mm
Length 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Number of Pins 28
