PIC18LF25K40-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~125C TA 32MHz 2.65mm 2K x 8
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.5928
≥1 USD $1.5928
≥10 USD $1.4608
≥100 USD $1.32
Inventory: 800
Minimum: 1
-
+
Technical Details
Technical
Series PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Additional Feature ALSO OPERATES WITH 2.5VMIN @32 MHZ AND 1.8VMIN @16MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number PIC18LF25K40
JESD-30 Code R-PDSO-G28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Data Converter A/D 35x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
Packaging Tube
Operating Temperature -40°C~125°C TA
DAC Channels YES
EEPROM Size 256 x 8
On Chip Program ROM Width 8
Screening Level TS 16949
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Dimensions
Height Seated (Max) 2.65mm
Length 17.9mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
