PIC18LF1320T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 28QFN
PDF
/
Buying Options
Total Price: USD $40.86
Unit Price: USD $40.858646
≥1 USD $40.858646
≥10 USD $38.545896
≥100 USD $36.364059
≥500 USD $34.305713
≥1000 USD $32.363882
Inventory: 1102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
Series PIC? 18F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature OPERATES AT 2V MIN SUPPLY
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18LF1320
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Interface UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 16
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 4K x 16
Connectivity UART/USART
Bit Size 8
Data Converter A/D 7x10b
Watchdog Timer Yes
Access Time 40 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
EEPROM Size 256 x 8
On Chip Program ROM Width 16
Dimensions
Height Seated (Max) 1mm
Length 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
