PIC18LC601-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT ROMLESS 64TQFP
PDF
/
Inventory: 1786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 64-TQFP
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2007
Series PIC? 18C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO OPERATES AT 2 V MINIMUM SUPPLY
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 25MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18LC601
Pin Count 64
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Supply Voltage-Min (Vsup) 2V
Interface EBI/EMI, I2C, SPI, UART, USART
Oscillator Type External
Number of I/O 26
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type ROMless
Core Size 8-Bit
Connectivity EBI/EMI, I2C, SPI, UART/USART
Supply Current-Max 50mA
Bit Size 8
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
Address Bus Width 16
ROM (words) 0
CPU Family PIC
Number of Programmable I/O 47
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
