PIC18F96J94T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 100TQFP
PDF
/
Buying Options
Total Price: USD $4.08
Unit Price: USD $4.076555
≥1 USD $4.076555
≥200 USD $1.578106
≥500 USD $1.522964
≥1200 USD $1.495393
Inventory: 1481
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-TQFP
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
Series PIC? XLP? 18J
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Frequency 64MHz
Base Part Number PIC18F96J94
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2.5/3.3V
Supply Voltage-Min (Vsup) 2V
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size 64kB
Oscillator Type Internal
Number of I/O 86
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 32K x 16
Connectivity I2C, IrDA, LINbus, SPI, UART/USART, USB
Supply Current-Max 7mA
Bit Size 8
Data Converter A/D 24x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
Address Bus Width 16
ROM (words) 32768
On Chip Program ROM Width 16
CPU Family PIC
Boundary Scan NO
External Data Bus Width 16
Number of Serial I/Os 4
Number of External Interrupts 48
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1.2mm
Length 12mm
Width 12mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
