PIC18F96J65-I/PF
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 96KB FLSH 12KB RAM
PDF
/
Buying Options
Total Price: USD $7.31
Unit Price: USD $7.3128
≥1 USD $7.3128
Inventory: 97
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 14mm
Height Seated (Max) 1.2mm
Technical
CPU Family PIC
ROM (words) 98304
Address Bus Width 20
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 16x10b
Bit Size 16
Supply Current-Max 21.6mA
Connectivity EBI/EMI, Ethernet, I2C, SPI, UART/USART
Program Memory Size 96KB 48K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2V~3.6V
RAM Size 3808 x 8
Speed 41.6667 MHz
Number of I/O 70
Oscillator Type Internal
Memory Size 96kB
Interface EBI/EMI, Ethernet, I2C, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Pin Count 100
Base Part Number PIC18F96J65
Time@Peak Reflow Temperature-Max (s) 40
Frequency 41.667MHz
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT 2V MINIMUM SUPPLY AT 4 MHZ
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.A.2
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18J
Published 2007
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 100
Package / Case 100-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
