PIC18F8628-E/PT
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 96KB Flash 4KB RAM 1024 DataEE 12B ADC
PDF
/
Inventory: 3120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12mm
Height Seated (Max) 1.2mm
Technical
CPU Family PIC
On Chip Program ROM Width 16
EEPROM Size 1K x 8
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 16x12b
Bit Size 8
Supply Current-Max 29mA
Connectivity EBI/EMI, I2C, SPI, UART/USART
Program Memory Size 96KB 48K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
RAM Size 3.8K x 8
Speed 40 MHz
Number of I/O 70
Oscillator Type Internal
Memory Size 96kB
Interface EBI/EMI, I2C, SPI, UART, USART
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 80
Base Part Number PIC18F8628
Time@Peak Reflow Temperature-Max (s) 40
Frequency 25MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18F
Published 2008
Packaging Tray
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 80
Package / Case 80-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
