PIC18F67J94T-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 64 pins 128KB Flash 4KB RAM 16MIPS
PDF
/
Inventory: 7836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
Series PIC? XLP? 18J
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 64MHz
Base Part Number PIC18F67J94
JESD-30 Code S-PQCC-N64
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2.5/3.3V
Supply Voltage-Min (Vsup) 2V
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Oscillator Type Internal
Number of I/O 52
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 128KB 64K x 16
Connectivity I2C, IrDA, LINbus, SPI, UART/USART, USB
Supply Current-Max 7mA
Bit Size 8
Data Converter A/D 16x10b/12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Address Bus Width 16
ROM (words) 65536
On Chip Program ROM Width 16
CPU Family PIC
Boundary Scan NO
External Data Bus Width 16
RAM (words) 4000
Number of Serial I/Os 4
Number of Timers 8
Number of External Interrupts 48
On Chip Data RAM Width 8
Supply Chain
Factory Lead Time 6 Weeks
Dimensions
Height Seated (Max) 1mm
Length 9mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
