PIC18F66K22-I/MRRSL
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 64QFN
PDF
/
Buying Options
Total Price: USD $94.46
Unit Price: USD $94.464561
≥1 USD $94.464561
≥10 USD $89.117518
≥100 USD $84.073126
≥500 USD $79.314275
≥1000 USD $74.824783
Inventory: 1364
Minimum: 1
-
+
Technical Details
Technical
Terminal Pitch 0.5mm
Frequency 64MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F66K22
Pin Count 64
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 3V
Interface I2C, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 53
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 32K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 32
Data Converter A/D 16x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
DAC Channels NO
Number of Timers/Counters 11
EEPROM Size 1K x 8
On Chip Program ROM Width 8
CPU Family PIC
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Additional Feature ALSO OPERATES WITH 1.8 V MIN SUPPLY AT 4 MHZ
Terminal Finish Matte Tin (Sn)
ECCN Code 3A001.A.3
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? XLP? 18K
Packaging Tube
Operating Temperature -40°C~85°C TA
Screening Level TS 16949
Number of PWM Channels 10
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Dimensions
Height Seated (Max) 1mm
Length 9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
