PIC18F6680-I/PTG
RoHS
/
Package TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 64KB 3328 RAM 52 I/O Lead Free Package
PDF
/
Inventory: 5799
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case TQFP
Surface Mount YES
Technical
Packaging Bulk
Pbfree Code yes
Number of Terminations 64
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 40MHz
Pin Count 64
JESD-30 Code S-PQFP-G64
Temperature Grade INDUSTRIAL
Interface CAN, I2C, SPI
Max Supply Voltage 5.5V
Min Supply Voltage 4.2V
Memory Size 64kB
Number of I/O 53
RAM Size 3.3kB
Memory Type FLASH
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Bit Size 8
Frequency (Max) 40MHz
Access Time 40 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 8
Core Architecture PIC
On Chip Program ROM Width 16
Screening Level TS 16949
Number of Programmable I/O 53
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
