PIC18F45K40-I/MV
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED POINT ROHS3Compliant NO LEAD QUAD Microcontroller -40C~85C TA 64MHz 0.55mm 2K x 8
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.716
≥1 USD $1.716
≥10 USD $1.584
≥100 USD $1.4344
Inventory: 1349
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 40-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2016
Series PIC? XLP? 18K
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature IT ALSO OPERATES AT 2.5V MIN AT 32 MHZ AND 2.3V MIN AT 16 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Frequency 64MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number PIC18F45K40
JESD-30 Code S-PQCC-N40
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 3V
Interface I2C, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 36
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 35x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 256 x 8
On Chip Program ROM Width 16
Boundary Scan NO
Low Power Mode YES
Screening Level TS 16949
Format FIXED POINT
Integrated Cache NO
RAM (words) 16384
Number of Timers 9
Number of External Interrupts 3
Dimensions
Height Seated (Max) 0.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
