PIC18F4585T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 48KB FLASH 44TQFP
PDF
/
Buying Options
Total Price: USD $8.28
Unit Price: USD $8.2808
≥1 USD $8.2808
Inventory: 1115
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-TQFP
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2007
Series PIC? 18F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F4585
Pin Count 44
Operating Supply Voltage 5V
Power Supplies 5V
Interface CAN, I2C, SPI, UART, USART
Memory Size 48kB
Oscillator Type Internal
Number of I/O 36
RAM Size 3.25K x 8
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 48KB 24K x 16
Connectivity CANbus, I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 11x10b
Watchdog Timer Yes
Access Time 40 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
EEPROM Size 1K x 8
On Chip Program ROM Width 16
CPU Family PIC
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
