PIC18F4523T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 44QFN
PDF
/
Inventory: 7882
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F4523
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 36
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Series PIC? 18F
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 13x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
EEPROM Size 256 x 8
On Chip Program ROM Width 16
CPU Family PIC
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Dimensions
Height Seated (Max) 1mm
Length 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
