PIC18F44J11T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC PIC MCU FLASH 16KB 44-TQFP
PDF
/
Inventory: 4153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-TQFP
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2009
Series PIC? XLP? 18J
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.8mm
Frequency 48MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F44J11
Pin Count 44
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 34
RAM Size 3.8K x 8
Voltage - Supply (Vcc/Vdd) 2.15V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 16KB 8K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 24.1mA
Bit Size 8
Data Converter A/D 13x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 8192
On Chip Program ROM Width 16
CPU Family PIC
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
