PIC18F27Q10-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
128KB FLASH 3.6KB RAM 1024B EEPR
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.2936
≥100 USD $1.1792
Inventory: 1132
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 18Q
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 1.27mm
JESD-30 Code R-PDSO-G28
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 3.53K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 128KB 128K x 8
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 5.8mA
Bit Size 8
Data Converter A/D 24x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 65536
EEPROM Size 1K x 8
On Chip Program ROM Width 16
Boundary Scan NO
Low Power Mode YES
Format FIXED-POINT
Integrated Cache NO
RAM (words) 3615
RAM (bytes) 3615
Number of Serial I/Os 2
Number of Timers 7
Number of External Interrupts 3
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 2.65mm
Length 17.9mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
