PIC18F27J53T-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 128KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $4.62
Unit Price: USD $4.62
≥1 USD $4.62
≥10 USD $4.2328
≥100 USD $3.8368
Inventory: 2728
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 16
CPU Family PIC
ROM (words) 131072
Number of Timers/Counters 8
Data Bus Width 8b
Watchdog Timer Yes
Data Converter A/D 10x10b/12b
Bit Size 8
Supply Current-Max 21.5mA
Connectivity I2C, LINbus, SPI, UART/USART, USB
Program Memory Size 128KB 64K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 2.15V~3.6V
RAM Size 3.8K x 8
Number of I/O 22
Oscillator Type Internal
Memory Size 128kB
Interface I2C, LIN, SPI, UART, USART, USB
Power Supplies 2.5/3.3V
Pin Count 28
Base Part Number PIC18F27J53
Frequency 48MHz
Terminal Pitch 0.635mm
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 18J
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 11 Weeks
