PIC18F26K80-H/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 28SSOP
PDF
/
Inventory: 1731
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TA
Packaging Tube
Published 2012
Series Automotive, AEC-Q100, PIC? XLP? 18K
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code 3A001.A.2.A
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Frequency 64MHz
Base Part Number PIC18F26K80
JESD-30 Code R-PDSO-G28
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 24
RAM Size 3.6K x 8
Voltage - Supply (Vcc/Vdd) 4V~5.5V
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 32K x 16
Connectivity ECANbus, I2C, LINbus, SPI, UART/USART
Supply Current-Max 32mA
Bit Size 8
Data Converter A/D 8x12b
Data Bus Width 8b
Number of Timers/Counters 5
ROM (words) 32768
EEPROM Size 1K x 8
On Chip Program ROM Width 16
CPU Family PIC
Compliance
RoHS Status ROHS3 Compliant
