PIC18F25K83-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 28QFN
PDF
/
Buying Options
Total Price: USD $2.06
Unit Price: USD $2.0592
≥1 USD $2.0592
≥10 USD $1.892
≥100 USD $1.716
Inventory: 1248
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 1mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
EEPROM Size 1K x 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 24x12b; D/A 1x5b
Connectivity CANbus, I2C, LINbus, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 2K x 8
Speed 64MHz
Number of I/O 25
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PQCC-N28
Base Part Number PIC18F25K83
Terminal Pitch 0.65mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature OPERATES AT 2.3V MINIMUM SUPPLY AT 16 MHZ
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 18K
Published 2018
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
