PIC18F25J10-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 28QFN
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.5479
≥1 USD $2.5479
≥10 USD $2.09095
≥100 USD $2.0254
≥500 USD $1.9608
≥1000 USD $1.89525
Inventory: 1598
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6mm
Length 6mm
Height 950μm
Technical
Number of SPI Channels 1
Number of I2C Channels 1
Number of PWM Channels 2
Number of ADC Channels 10
Number of Programmable I/O 21
Max Frequency 40MHz
Core Architecture PIC
Number of Timers/Counters 3
Data Bus Width 8b
Access Time 40 μs
Watchdog Timer Yes
Data Converter A/D 10x10b
Connectivity I2C, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 2.7V~3.6V
Memory Type FLASH
RAM Size 1K x 8
Speed 40MHz
Number of I/O 21
Oscillator Type Internal
Memory Size 32kB
Min Supply Voltage 4.2V
Max Supply Voltage 5.5V
Interface I2C, SPI, UART, USART
Operating Supply Voltage 5V
Base Part Number PIC18F25J10
Frequency 40MHz
Max Power Dissipation 1W
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series PIC? 18J
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 28-QFN (6x6)
Number of Pins 28
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
