PIC18F2580-E/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 32 KB FL 1536 RAM 25 I/O
PDF
/
Buying Options
Total Price: USD $7.88
Unit Price: USD $7.876
≥1 USD $7.876
Inventory: 1138
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2007
Series PIC? 18F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 4.5V
Terminal Pitch 0.65mm
Frequency 25MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F2580
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Interface CAN, I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 25
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity CANbus, I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Access Time 40 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 4
EEPROM Size 256 x 8
CPU Family PIC
Number of ADC Channels 8
Number of I2C Channels 1
Dimensions
Height 950μm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
