PIC18F2520T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC PIC MCU FLASH 16KX16 28QFN
PDF
/
Buying Options
Total Price: USD $5.6
Unit Price: USD $5.5968
≥1 USD $5.5968
Inventory: 1231
Minimum: 1
-
+
Technical Details
Technical
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.A.2
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18F
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
CPU Family PIC
On Chip Program ROM Width 16
EEPROM Size 256 x 8
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 40 μs
Watchdog Timer Yes
Data Converter A/D 10x10b
Bit Size 8
Supply Current-Max 20mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
RAM Size 1.5K x 8
Number of I/O 25
Oscillator Type Internal
Memory Size 32kB
Interface I2C, SPI, UART, USART
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 28
Base Part Number PIC18F2520
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Physical
Number of Pins 28
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 6mm
Height Seated (Max) 1mm
