PIC18F24Q10-I/SS
RoHS
/
Package 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.0032
≥1 USD $1.0032
≥10 USD $0.9152
≥100 USD $0.8448
Inventory: 20853
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 18Q
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC18F24Q10
JESD-30 Code R-PDSO-G28
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 25
Speed 64MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, SPI, UART/USART
Data Converter A/D 24x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 256 x 8
On Chip Program ROM Width 8
Compliance
RoHS Status Non-RoHS Compliant
