PIC18F2423-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 16KB FL 768bytes- RAM 25I/O
PDF
/
Buying Options
Total Price: USD $5.38
Unit Price: USD $5.3768
≥1 USD $5.3768
≥10 USD $5.290912
Inventory: 160
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2005
Series PIC? 18F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F2423
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Interface I2C, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 25
RAM Size 768 x 8
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 16KB 8K x 16
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 10x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 4
EEPROM Size 256 x 8
CPU Family PIC
Number of ADC Channels 10
Number of I2C Channels 1
Dimensions
Height 950μm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
