PIC18F2410T-I/ML
RoHS
/
Package 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB FLASH 28QFN
PDF
/
Buying Options
Total Price: USD $3.05
Unit Price: USD $3.0514
≥1 USD $3.0514
≥10 USD $2.5042
≥100 USD $2.42535
≥500 USD $2.34745
≥1000 USD $2.26955
Inventory: 32581
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2004
Series PIC? 18F
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 40MHz
Base Part Number PIC18F2410
Pin Count 28
JESD-30 Code S-PQCC-N28
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Interface I2C, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 25
RAM Size 768 x 8
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 16KB 8K x 16
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 10x10b
Watchdog Timer Yes
Access Time 40 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
ROM (words) 8192
On Chip Program ROM Width 16
CPU Family PIC
Dimensions
Height Seated (Max) 1mm
Length 6mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
