PIC18F23K22-I/MV
RoHS
RoHS compliant
RoHS compliantPackage 28-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 28UQFN
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
≥10 USD $2.1032
≥100 USD $1.892
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-UFQFN Exposed Pad
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2010
Series PIC? XLP? 18K
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.4mm
Frequency 64MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC18F23K22
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Interface I2C, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 24
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 4K x 16
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 19x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 7
ROM (words) 4096
EEPROM Size 256 x 8
CPU Family PIC
Number of A/D Converters 2
Number of Programmable I/O 25
Number of ADC Channels 17
Dimensions
Height 500μm
Length 5mm
Width 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
