PIC18F23K20-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $11.6
Unit Price: USD $11.603032
≥1 USD $11.603032
≥10 USD $10.946259
≥100 USD $10.326661
≥500 USD $9.74213
≥1000 USD $9.190687
Inventory: 1362
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10.2mm
Height Seated (Max) 2mm
Technical
Number of Programmable I/O 25
CPU Family PIC
On Chip Program ROM Width 16
EEPROM Size 256 x 8
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 11x10b
Bit Size 8
Supply Current-Max 15mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 8KB 4K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 512 x 8
Number of I/O 24
Oscillator Type Internal
Memory Size 8kB
Interface I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 2/3.3V
Supply Voltage-Max (Vsup) 3.5V
Pin Count 28
Base Part Number PIC18F23K20
Time@Peak Reflow Temperature-Max (s) 40
Frequency 48MHz
Terminal Pitch 0.65mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT 1.8V MINIMUM SUPPLY FOR 20 MHZ
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A991.A.2
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? XLP? 18K
Published 2009
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 28
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
