PIC18F13K22-E/P
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20DIP
PDF
/
Buying Options
Total Price: USD $31.72
Unit Price: USD $31.719029
≥1 USD $31.719029
≥10 USD $29.92361
≥100 USD $28.229821
≥500 USD $26.631908
≥1000 USD $25.124438
Inventory: 1555
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Number of Pins 20
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2008
Series PIC? XLP? 18K
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 3.6V
Frequency 48MHz
Base Part Number PIC18F13K22
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 2.7V
Interface I2C, LIN, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 17
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 4K x 16
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 15.6mA
Bit Size 16
Data Converter A/D 12x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 4
EEPROM Size 256 x 8
On Chip Program ROM Width 16
CPU Family PIC
Number of Programmable I/O 18
Dimensions
Length 26.162mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
