PIC18C242-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB OTP 28SOIC
PDF
/
Inventory: 2534
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 17.87mm
Technical
Number of Programmable I/O 23
CPU Family PIC
On Chip Program ROM Width 16
ROM (words) 8192
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 5x10b
Bit Size 8
Supply Current-Max 50mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 16KB 8K x 16
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 4.2V~5.5V
Memory Type EPROM
RAM Size 512 x 8
Number of I/O 22
Oscillator Type External
Memory Size 16kB
Interface I2C, SPI, UART, USART
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 28
Base Part Number PIC18C242
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 18C
Published 2002
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
