PIC17LC766T-08I/PT
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB OTP 80TQFP
PDF
/
Inventory: 8686
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12mm
Height Seated (Max) 1.2mm
Technical
On Chip Program ROM Width 16
Address Bus Width 16
Number of Timers/Counters 8
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 8 μs
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 8
Connectivity I2C, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~5.5V
Memory Type EPROM
RAM Size 902 x 8
Number of I/O 66
Oscillator Type External
Memory Size 16kB
Interface I2C, RS-232, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 80
Base Part Number PIC17LC766
Time@Peak Reflow Temperature-Max (s) 40
Frequency 8MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Terminal Finish Matte Tin (Sn)
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 17C
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 80
Surface Mount YES
Package / Case 80-TQFP
Mounting Type Surface Mount
