PIC17LC762-08/PT
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB OTP 80TQFP
PDF
/
Inventory: 7043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 80-TQFP
Surface Mount YES
Number of Pins 80
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2013
Series PIC? 17C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC17LC762
Pin Count 80
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 3V
Interface I2C, RS-232, SCI, SPI, UART, USART
Memory Size 8kB
Oscillator Type External
Number of I/O 66
RAM Size 678 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 16KB 8K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 8
Data Converter A/D 16x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 8
Address Bus Width 16
On Chip Program ROM Width 16
CPU Family PIC
Dimensions
Height Seated (Max) 1.2mm
Length 12mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
