PIC17LC43-08/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB OTP 44TQFP
PDF
/
Inventory: 1581
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Number of Pins 44
Surface Mount YES
Package / Case 44-TQFP
Technical
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 8KB 4K x 16
Connectivity UART/USART
Supply Current-Max 12mA
Bit Size 8
Watchdog Timer Yes
Access Time 8 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 8
Address Bus Width 16
ROM (words) 4096
On Chip Program ROM Width 16
CPU Family PIC
Peripherals POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~6V
Memory Type EPROM
RAM Size 454 x 8
Number of I/O 33
Oscillator Type External
Memory Size 4kB
Interface SCI, UART, USART
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 6V
Pin Count 44
Base Part Number PIC17LC43
Time@Peak Reflow Temperature-Max (s) 40
Frequency 8MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 17C
Published 1996
Packaging Tray
Operating Temperature 0°C~70°C TA
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
